Stencil : xemu-0.7.98-master-7bfb7c85378f64f93556c365ea0cc18cb2181dc8:Linux_x86_64:gl_Mesa_NV134:gslv_4.30 vs Xbox_Hardware

Description

Tests the behavior of NV097_SET_STENCIL_OP_ZPASS.

Each test renders a red quad, then enables stencil testing, renders a smaller quad into the depth/stencil buffer to update stencil values, then renders a green quad over the original red. Areas that pass the stencil test will be green, other areas will remain red.

Suite class def

src/tests/stencil_tests.h

Golden results

https://abaire.github.io/nxdk_pgraph_tests_golden_results/results/Stencil/index.html

Stencil_REPLACE

Difference

0.13808104395866394

Diff result for Stencil::Stencil_REPLACE

Source image for Stencil::Stencil_REPLACE

Stencil_REPLACE_DT

Difference

0.13849934935569763

Diff result for Stencil::Stencil_REPLACE_DT

Source image for Stencil::Stencil_REPLACE_DT

Stencil_REPLACE_ST

Difference

0.1496063470840454

Diff result for Stencil::Stencil_REPLACE_ST

Source image for Stencil::Stencil_REPLACE_ST

Stencil_REPLACE_ST_DT

Difference

0.15013642609119415

Diff result for Stencil::Stencil_REPLACE_ST_DT

Source image for Stencil::Stencil_REPLACE_ST_DT

Stencil_REPLACE_ST_DT_ZB

Difference

1.560112286824733e-05

Diff result for Stencil::Stencil_REPLACE_ST_DT_ZB

Source image for Stencil::Stencil_REPLACE_ST_DT_ZB

Stencil_REPLACE_ST_ZB

Difference

1.560112286824733e-05

Diff result for Stencil::Stencil_REPLACE_ST_ZB

Source image for Stencil::Stencil_REPLACE_ST_ZB

Stencil_ZERO

Difference

0.13808639347553253

Diff result for Stencil::Stencil_ZERO

Source image for Stencil::Stencil_ZERO

Stencil_ZERO_DT

Difference

0.13850975036621094

Diff result for Stencil::Stencil_ZERO_DT

Source image for Stencil::Stencil_ZERO_DT

Stencil_ZERO_ST

Difference

0.14961309731006622

Diff result for Stencil::Stencil_ZERO_ST

Source image for Stencil::Stencil_ZERO_ST

Stencil_ZERO_ST_DT

Difference

0.15013550221920013

Diff result for Stencil::Stencil_ZERO_ST_DT

Source image for Stencil::Stencil_ZERO_ST_DT

Stencil_ZERO_ST_DT_ZB

Difference

0.22055692970752716

Diff result for Stencil::Stencil_ZERO_ST_DT_ZB

Source image for Stencil::Stencil_ZERO_ST_DT_ZB

Stencil_ZERO_ST_ZB

Difference

0.22055692970752716

Diff result for Stencil::Stencil_ZERO_ST_ZB

Source image for Stencil::Stencil_ZERO_ST_ZB
